Automatic condensate from ladder AOK 20 B
- For the automatic, level-controlled discharge of condensate or other non-aggressive liquids from the compressed air system
- Compressed air temperature range: 1.5-65 ° C
- To derive a higher volume of condensate from compressed air filters, pressure vessels and Cyclone separators without air loss
- External lightning arrester with robust aluminium housing
- Separation efficiency at 7 bar: 167 l / h
- Condensate inlet G ½ ", condensate drain G ½"
- Equipped with manual condensate drain valve
- maximum operating pressure: 20 bar
- Dimensions: 135 x 110 x 130 mm
